Pure electric van transporter Yuda V7
1.The front MacPherson suspension and the rear steel plate spring suspension improve the comfort and handling stability of the vehicle.
2.Front disc and rear drum hydraulic brake meets the needs of high requirements for brake heat dissipation.
3.Intensive full-stamping load-bearing structure design, both of the body and the bearing capacity are stronger.
4.The design of double doors and side sliding door are convenient for customer operation and improves loading and unloading efficiency.
5.Electric power steering system can lightly and flexibly control the steering, and the control is accurate and in place.
6.Long auto body, large wheelbase, large volume and high load capacity, enables it to carry larger volume and longer cargo.
| System | EC712/Pure Electric Microvan (Basic configuration) |
|||
| Basic parameters |
Driver's cab width |
1715 (single row) |
||
| Wheelbase (mm) |
3450 |
|||
| Drive motor |
Manufacturer |
Yuchai Xinlan |
||
| Rated/Peak Power (kW) |
35/70 |
|||
| Rated/peak torque (N.m) |
90/220 |
|||
| Battery |
Manufacturer |
EVE POWER | ||
| Electric quantity (kWh) |
46.368 |
|||
| External dimensions |
Length (mm) |
5265 |
||
| Width (mm) |
1715 |
|||
| Height (mm) | 2065 |
|||
| Wheel track |
Front (mm) |
1460 |
||
| Back (mm) |
1465 |
|||
| Overhang length | Front (mm) |
750 |
||
| Back (mm) |
1065 | |||
| Front and rear axles |
Before (T) |
1.5 | ||
| After (T) |
2 | |||
| Main reduction |
Speed ratio |
10.5 | ||
| Storage battery |
Capacity (Ah) |
45 | ||
| Lighting fixtures |
Front combination lamp |
Electric adjustable headlights |
● | |
| LED | X | |||
| Halogen | ● | |||
| Fog lights |
Front fog lights |
X | ||
| Rear fog lights |
● | |||
| High mounted brake light |
● | |||
| Interior |
Combination instrument | LCD screen |
X | |
| Segment code LCD screen |
● | |||
| Seat | Knitted fabric | ● | ||
| Driver's seat | 4-way manual adjustment (Seat cushion fore and aft adjustment+backrest fore and aft adjustment) |
● | ||
| Passenger seat | 4-way manual adjustment (Seat cushion fore and aft adjustment+backrest fore and aft adjustment) |
● | ||
| Shift mechanism | Rotary electronic shifter |
● | ||
| Car audio and video |
Radio |
X | ||
| Multimedia |
X | |||
| Reverse radar |
X | |||
| Comfort | Heating and cooling air conditioning | ● | ||
| Sun visor |
Driver's side |
● | ||
| Co pilot's side | X |
|||
| Vehicle body and its accessories |
Standard configuration |
1. Front door electric window; 2. Full package interior design; 3. Cabin cargo compartment enclosed partition: fully enclosed partition; 4. Vehicle tools: 1 trailer hook, 1 jack, 2 screwdrivers, 1 10-13 wrench, 1 16-18 wrench, 1 extended pry bar, 1 tire insert (19-21) 5. Triangle warning signs and reflective vests |
● | |
| Other |
Charging system |
Fast charging |
● | |
| Slow charging | ● | |||
| Cargo compartment |
Cargo compartment size |
3205*1550*1350 |
● | |
| Floor material |
Composite pattern board |
● | ||
| Security | ABS |
● | ||
| Electric Power Steering (EPS) |
● | |||
| Vacuum assisted |
● | |||
| Reverse voice warning |
● | |||
| Pedestrian reminder |
● | |||
| Wheel | Steel wheel |
● | ||
| Tire specifications |
195R14C 8PR | ● | ||
| Spare tire | ● | |||
Symbol Description: ● Standard, ○ Optional, X does not have this configuration
